Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1830
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (usb) FRINDEX
URE
(IXR_UR)
6 rw 0x0 USB Reset Received Interrupt Enable (Device
mode).
0: disable.
1: enable interrupt on receiving USB reset.
Refer to raw interrupt status: USBSTS [URI].
AAE
(IXR_AA)
5 rw 0x0 Async Advance Interrupt Enable (EHCI).
0: disable.
1: enable.
Refer to raw interrupt status: USBSTS [AAI].
SEE 4 rw 0x0 System Error Interrupt Enable (EHCI).
0: disable.
1: enable.
Refer to raw interrupt status: USBSTS [SEI].
FRE
(IXR_FRE)
3 rw 0x0 Frame List Rollover Interrupt Enable (EHCI).
0: disable.
1: enable.
Refer to raw interrupt status: USBSTS [FRI].
PCE
(IXR_PC)
2 rw 0x0 Port Change Detect Interrupt Enable (EHCI).
0: disable.
1: enable.
Refer to raw interrupt status: USBSTS [PCI].
UEE
(IXR_UE)
1 wtc 0x0 USB Error Interrupt Enable (EHCI).
0: disable.
1: enable.
Refer to raw interrupt status: USBSTS [UEI].
UE
(IXR_UI)
0 rw 0x0 USB Interrupt Enable (EHCI).
0: disable.
1: enable.
Refer to raw interrupt status: USBSTS [UI].
Name FRINDEX
Software Name FRAME
Relative Address 0x0000014C
Absolute Address usb0: 0xE000214C
usb1: 0xE000314C
Width 14 bits
Access Type rw
Field Name Bits Type Reset Value Description
