Appendix B: Register Details
Register (usb) TXTTFILLTUNING
Register TXTTFILLTUNING Details
This register provides a function similar to TXFILLTUNING except there is no equivalent to
TXFIFOTHRES because the TT TX latency FIFO is always loaded in a single burst. Even
Register (usb) IC_USB
Register IC_USB Details
This register enable and controls the IC_USB FS/LS transceiver.
Name TXTTFILLTUNING
Relative Address 0x00000168
Absolute Address usb0: 0xE0002168
usb1: 0xE0003168
Width 13 bits
Access Type mixed
Reset Value 0x00000000
Description TT TX latency FIFO
Field Name Bits Type Reset Value Description
TXTTSCHHEALTH 12:8 rw 0x0 TT Scheduler Health Counter
Same description as TXSCHHEALTH
reserved 7:5 ro 0x0 reserved
TXTTSCHOH 4:0 rw 0x0 TT Scheduler Overhead
Same description as TXSCHOH.
The time unit represented in this register is
6.333us.
Name IC_USB
Relative Address 0x0000016C
Absolute Address usb0: 0xE000216C
usb1: 0xE000316C
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description Low and Fast Speed Control constants
