Appendix B: Register Details
Register (usb) ENDPTNAK
Register ENDPTNAK Details
Register (usb) ENDPTNAKEN
Name ENDPTNAK
Software Name EPNAKISR
Relative Address 0x00000178
Absolute Address usb0: 0xE0002178
usb1: 0xE0003178
Width 32 bits
Access Type wtc
Reset Value 0x00000000
Description Endpoint NAK (Device mode)
Field Name Bits Type Reset Value Description
EPTN 31:16 wtc 0x0 TX Endpoint NAK (Device mode).
The Endpoint bit is set = 1 when the device
controller sends a NAK handshake on a received
IN token for the corresponding endpoint.
Bit[16]: Endpoint 0.
Bit[17]: Endpoint 1.
...
Bit[28]: Endpoint 12.
Bits[31:29]: reserved.
EPRN 15:0 wtc 0x0 RX Endpoint NAK (Device mode).
The bit is set = 1 when the Controller sends a NAK
handshake on a received OUT or PING token for
the corresponding endpoint.
Bit[0]: Endpoint 0.
Bit[1]: Endpoint 1.
...
Bit[12]: Endpoint 12.
Bits[15:13]: reserved.
Name ENDPTNAKEN
Software Name EPNAKIER
Relative Address 0x0000017C
Absolute Address usb0: 0xE000217C
usb1: 0xE000317C
Width 32 bits
