Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1843
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register ENDPTNAKEN Details
Register (usb) CONFIGFLAG
Access Type rw
Reset Value 0x00000000
Description Endpoint NAK (Device mode)
Field Name Bits Type Reset Value Description
EPTNE 31:16 rw 0x0 TX Endpoint NAK Enable (Device mode).
0: disable.
1: enable.
Each bit is an enable bit for the corresponding TX
Endpoint NAK. If NAK is enabled and the
corresponding TX Endpoint NAK bit is set, then
the NAK Interrupt bit is set.
Bit[16]: Endpoint 0.
Bit[17]: Endpoint 1.
...
Bit[28]: Endpoint 12.
Bits[31:29]: reserved.
EPRNE 15:0 rw 0x0 RX Endpoint NAK Enable (Device mode).
0: disable.
1: enable.
Each bit is an enable bit for the corresponding RX
Endpoint NAK. If NAK is enabled and the
corresponding RX Endpoint NAK bit is set, then
the NAK Interrupt bit is set.
Bit[0]: Endpoint 0.
Bit[1]: Endpoint 1.
...
Bit[12]: Endpoint 12.
Bits[15:13]: reserved.
Name CONFIGFLAG
Relative Address 0x00000180
Absolute Address usb0: 0xE0002180
usb1: 0xE0003180
Width 32 bits
Access Type ro
Reset Value 0x00000001
Description reserved
