Appendix B: Register Details
BSEIS
(OTGSC_BSEIS)
20 wtc 0x0 B Session End Interrupt Status.
0: no event detected.
1: event detected. Write 1 to clear bit.
This bit is set when VBus has fallen below the B
session end threshold.
BSVIS
(OTGSC_BSVIS)
19 wtc 0x0 B Session Valid Interrupt Status.
0: no event detected.
1: event detected. Write 1 to clear bit.
This bit is set when VBus has either risen above or
fallen below the B session valid threshold (0.8
VDC).
ASVIS
(OTGSC_ASVIS)
18 wtc 0x0 A Session Valid Interrupt Status.
0: no event detected.
1: event detected. Write 1 to clear bit.
This bit is set when VBus has either risen above or
fallen below the B session valid threshold (0.8
VDC).
AVVIS
(OTGSC_AVVIS)
17 wtc 0x0 A Session End Interrupt Status.
0: no event detected.
1: event detected. Write 1 to clear bit.
This bit is set when VBus has either risen above or
fallen below the VBus valid threshold (4.4 VDC)
on an A device.
IDIS
(OTGSC_IDIS)
16 wtc 0x0 USB ID Interrupt Status.
0: no interrupt latched
1: interrupt detected. Write 1 to clear this bit.
This bit is set when a change on the ID input has
been detected.
reserved 15 ro 0x0 reserved
DPS
(OTGSC_DPS)
14 ro 0x0 Data Bus Pulsing Status, read-only.
0: no pulses being detected.
1: pulses are being detected.
Note: refer to the [DPSI] bit for more information.
1msT
(OTGSC_1MST)
13 ro 0x0 1 ms Timer High-Low Toggle, read-only. Software
will usually read a 0.
This bit toggles high-low every millisecond to set
the [1msS] bit.
BSE
(OTGSC_BSE)
12 ro 0x1 B Session End Status, read-only.
0: Vbus not below threshold.
1: Vbus below threshold.
Field Name Bits Type Reset Value Description
