Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1861
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register ENDPTCTRL1 to ENDPTCTRL11 Details
Field Name Bits Type Reset Value Description
TXE 23 rw 0x0 TX Endpoint Enable.
0: disable.
1: enable.
Enable an Endpoing after it has been configured.
TXR 22 rw 0x0 TX Data Toggle Reset.
Write '1' will reset the PID sequence. Whenever a
configuration event is received for this Endpoint,
software must write a one to this bit in order to
synchronize the data PID's between the host and
device.
TXI 21 ro 0x0 TX Data Toggle Inhibit. (testing)
0: PID Sequencing enabled
1: PID Sequencing disabled
reserved 20 ro 0x0 reserved
TXT 19:18 rw 0x0 TX Endpoint Type control.
00: Control
01: Isochronous
10: Bulk
11: Interrupt
TXD 17 rw 0x0 TX Endpoint Data datapath.
0: dual-port memory buffer with a DMA Engine.
Always write a 0.
TXS 16 rw 0x0 TX Endpoint Stall.
0: Normal operation.
1: Force Stall handshake.
Note: refer to the ENDPTCTRL 0 register
description for more description.
reserved 15:8 ro 0x0 reserved
RXE 7 rw 0x0 RX Endpoint Enable
0: Disable
1: Enable
Enable an Endpoing after it has been configured.
RXR 6 rw 0x0 RX Data Toggle Reset.
Write '1' will reset the PID sequence. Whenever a
configuration event is received for this Endpoint,
software must write a one to this bit in order to
synchronize the data PID's between the host and
device.
RXI 5 rw 0x0 RX Data Toggle Inhibit.
0: PID Sequencing enabled
1: PID Sequencing disabled
