Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1862
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Access Types Legend
reserved 4 rw 0x0 reserved
RXT 3:2 rw 0x0 RX Endpoint Type.
00: Control
01: Isochronous
10: Bulk
11: Interrupt
RXD 1 rw 0x0 RX Endpoint Data datapath.
0: dual-port memory buffer with a DMA Engine.
Always write a 0.
RXS 0 rw 0x0 RX Endpoint Stall.
0: Normal operation.
1: Force Stall handshake.
Note: refer to the ENDPTCTRL 0 register
description for more description.
Access Type Description
clronrd Readable, clears value on read
clronwr Readable, clears value on write
nsnsro During non-secure access, if thread is non-secure, it is read only
nsnsrw During non-secure access, if thread is non-secure, it is read write
nsnswo During non-secure access, if thread is non-secure, it is write only
nssraz During non-secure access, if thread is secure, it is read as zero
raz Read as zero
ro Read-only
rs w: no effect, r: sets all bits
rud Read undefined
rw Normal read/write
rwso Read/write, set only
sro During secure access, it is read only
srw During secure access, it is read write
swo During secure access, it is write only
w0c w: 1/0 no effect on/clears matching bit, r: no effect
w0crs w: 1/0 no effect on/clears matching bit, r: sets all bits
w0s w: 1/0 no effect on/sets matching bit, r: no effect
Field Name Bits Type Reset Value Description
