Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 200
UG585 (v1.11) September 27, 2016
Chapter 6: Boot and Configuration
0x2102
P: Non-secure
NP: Previous
The address value in the Source Offset word
points to a location within the BootROM
Header instead of where the image is
actually located.
• Check the address value in the Source
Offset word.
0x2103
P: Non-secure
NP: Previous
The address value in the Source Offset word
is not aligned to a 64B boundary.
• Align the address in the Source Offset
word to a 64-byte boundary.
0x2106
P: Non-secure
NP: Previous
Non-secure and execute from OCM mode.
The Length of Image parameter exceeds the
192 KB limit of the OCM for the initial
FSBL/User code.
• Reduce the size of the initial FSBL/User
code that is loaded into the OCM.
0x2108
P: Non-secure
NP: Previous
Non-secure and execute from OCM mode.
The Start of Execution parameter is greater
than 192 KB (0x03 0000).
• The Start of Execution value must be
within the OCM.
0x2109
P: Non-secure
NP: Previous
The Reserved parameter (0x038) is not set =
0.
• Set the reserved parameter at 0x038 to
0.
0x210A
P: Non-secure
NP: Previous
Applies to secure boot mode. The Length of
Image word in the header is set to 0
(execute-in-place).
• Execute-in-place is not supported in
secure mode. Either specify non-secure
mode, or change the Length of Image
word to match the image length after
decryption.
0x210B
P: Secure
NP: Previous
Secure mode. HMAC error occurred.
• Verify that the key and key source are the
same for encryption and decryption.
0x210D
P: Header
NP: Previous
This error occurs if the image length is not
equal to 0 and the length is greater than
192 KB.
• Reduce the size of the initial FSBL/User
code that is loaded into the OCM.
0x210E
P: Header
NP: Previous
The Length of Image parameter is set to 0
indicating an execute-in-place boot, but the
selected boot mode does not support
execute-in-place.
• Check the boot mode settings.
• NAND and SD card do not support
execute-in-place.
0x210F
P: Header
NP: Previous
BootROM Header checksum failed before
processing the Register Initialization words.
• Verify that the Header Checksum is
correct.
• Verify that the boot device can be
accessed reliably using the JTAG boot
mode.
0x2110
P: Header
NP: Previous
The Image Identification word in the
BootROM Header does not contain
0x584C4E58, 'XLNX'.
•
Make sure the Image Identification word
has 0x584C4E58.
• Verify that the boot device can be
accessed reliably by using the JTAG boot
mode to download test software.
0x2111
P: Header
NP: Previous
One or more address/write-data pairs in the
Register Initialization section of the
BootROM contains an address outside of the
allowed range.
• Make sure the addresses in the Register
Initialization section are within the
ranges defined in the TRM table 6-13
Boot Image Address-Data Write Address
Ranges.
Table 6-20: BootROM Error Codes (Cont’d)
Error
Code
Lockdown
Type
(1)
Description Solution
