Chapter 6: Boot and Configuration
6.3.13 Post BootROM State
The state of the PS after the BootROM executes depends on these conditions:
• Decryption Status parameter.
• Boot strap mode pins.
• Actions of the BootROM based on system discovery.
The mode pins impact which MIO are enabled and what I/O standard they are set to after exiting the
BootROM. Additionally, the mode setting impacts the boot peripheral settings. For example, if
Quad-SPI is the selected boot source, the needed MIO is enabled and the Quad-SPI controller is set
with the necessary settings to read from flash. The modified values for each boot source are
documented in the associated boot devices section.
APU and OCM State after BootROM
The general processor state upon BootROM exit is as follows:
• MMU, Icache, Dcache, L2 cache are all disabled.
• Both processors are in the supervisor state.
• ROM code is inaccessible.
• 192 KB of OCM memory is accessible starting at address
0x0000_0000 while the upper 64 KB of
the OCM is accessible starting at address
0xFFFF_0000.
• CPU 0 branches into the stage 1 boot image if no failure takes place.
• CPU 1 is in a WFE state while executing code located at address
0xFFFF_FE00 to 0xFFFF_FFF0.
Memory Map During BootROM Execution
The system memory map during BootROM execution places 192 KB of OCM at the bottom of
memory and 64 KB at the top as shown in Figure 6-11. The 64 KB memory block is used is used by
the BootROM to store the BootROM Header and program variables. After the BootROM is finished,
the 64 KB OCM memory block is freed-up for the FSBL to use.
0x2200
P: Secure
NP: Previous
Secure boot mode. The image size after
decryption does fit into the 192 KB of
available OCM memory.
• Reduce the size of the initial FSBL/User
code that is loaded into the OCM.
Notes:
1. There are two reset types, POR (P) and non-POR (NP). Refer to the text preceding the table for an explanation of the
lockdown type column.
Table 6-20: BootROM Error Codes (Cont’d)
Error
Code
Lockdown
Type
(1)
Description Solution
