Chapter 8: Timers
8.5 Triple Timer Counters (TTC)
The TTC contains three independent timers/counters. There are two TTC modules in the PS, for a total
of six timers/counters. TTC 1 controller can be configured for secure or non-secure mode using the
nic301_addr_region_ctrl_registers.security_apb [ttc1_apb] register bit. The three timers within a TTC
controller have the same security state.
8.5.1 Features
Each of the triple timer counters has:
• Three independent 16-bit prescalers and 16-bit up/down counters
• Selectable clock input from:
°
Internal PS bus clock (CPU_1x)
°
Internal clock (from PL)
°
External clock (from MIO)
• Three interrupts, one for each counter
• Interrupt on overflow, at regular interval, or counter matching programmable values
• Generates waveform output (for example, PWM) through the MIO and to the PL
8.5.2 Block Diagram
A block diagram of the TTC is shown in Figure 8-3. The clock-in and wave-out multiplexing for
Timer/Clock 0 is controlled by the slcr.MIO_PIN_xx registers. If no selection is made in these
registers, then the default becomes the EMIO interface.
