Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 256
UG585 (v1.11) September 27, 2016
Chapter 9: DMA Controller
9.2 Functional Description
Common to all DMAC operating conditions
• 9.2.1 DMA Transfers on the AXI Interconnect
• 9.2.2 AXI Transaction Considerations
• 9.2.3 DMA Manager
• 9.2.4 Multi-channel Data FIFO (MFIFO)
Memory-to-memory transfers are managed by the DMAC
• 9.2.5 Memory-to-Memory Transfers
When the PL Peripheral Request Interface is used
• 9.2.6 PL Peripheral AXI Transactions
• Length management option: 9.2.8 PL Peripheral - Length Managed by PL Peripheral
• Length management option: 9.2.9 PL Peripheral - Length Managed by DMAC
Advanced DMAC operating features
• 9.2.10 Events and Interrupts
• 9.2.11 Aborts
• 9.2.12 Security
IP core Configuration
• Based on the ARM PrimeCell DMA Controller (PL330) refer to 9.2.13 IP Configuration Options
