Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 31
UG585 (v1.11) September 27, 2016
Chapter 1: Introduction
1.2 Processing System (PS) Features and
Descriptions
1.2.1 Application Processor Unit (APU)
The application processor unit (APU) provides an extensive offering of high-performance features
and standards-compliant capabilities.
Dual/Single ARM Cortex-A9 MPCore CPUs with ARM v7
• Run time options allow single processor, asymmetrical (AMP) or symmetrical multiprocessing
(SMP) configurations
• ARM version 7 ISA: standard ARM instruction set and Thumb®-2, Jazelle® RCT and Jazelle DBX
Java™ acceleration
• NEON™ 128b SIMD coprocessor and VFPv3 per MPCore
•32KB instruction and 32KB data L1 caches with parity per MPCore
• 512 KB of shareable L2 cache with parity
• Private timers and watchdog timers
System Features
• System-Level Control Registers (SLCRs)
°
A group of various registers that are used to control the PS behavior
°
The register map is located in Chapter 4, System Addresses
°
The SLCR registers related to a specific chapter are listed in the register overview table of
that chapter and detailed in Appendix B, Register Details
• Snoop control unit (SCU) to maintain L1 and L2 coherency
• Accelerator coherency port (ACP) from PL (master) to PS (slave)
°
64b AXI slave port
°
Can access the L2 and the OCM
°
Transactions are data coherent with L1 and L2 caches
• 256 KB of on-chip SRAM (OCM) with parity
°
Dual ported
°
Accessible by the CPUs, PL and central interconnect
°
At level of L2, but is not cacheable
• DMA controller
°
Four channels for PS (memory copy to/from any memory in system)
°
Four channels for PL (memory to PL, PL to memory)
