Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 415
UG585 (v1.11) September 27, 2016
Chapter 15: USB Host, Device, and OTG Controller
controller. The operation of an endpoint and use of queue heads are described later in this
document.
15.5.3 Endpoint Registers
The endpoint registers are listed in Table 15-4 USB Device Endpoint Register Summary. These
registers were summarized at the end of Table 15-1, page 407.
In general, there is one bit for each endpoint. The lower half of the register bits are for Rx endpoints
and the upper half is for Tx endpoints. Exceptions include the ENDPTSETUPSTAT and the endpoint
control registers, ENDPTCTRL{11:0}.
Endpoint Registers
Table 15-4: USB Device Endpoint Register Summary
Register Name
Description and Register Bit Field
Type
Tx Endpoint (11:0) Rx Endpoint (11:0)
ENDPTNAK
Bit is set when an endpoint sends a NAK to the Host. Read and
Write-one-to-clear.
[EPTN], 27:16
(IN token)
[EPRN], 11:0
(OUT or Ping token)
ENDPTNAKEN
Interrupt enable bits for ENDPTNAK bits. Read/Write.
[EPTNE], 27:16 [EPRNE], 11:0
ENDPTSETUPSTAT
Bit is set when an endpoint receives a Setup transaction. Read and
Write-one-to-clear.
~ [ENDPTSETUPSTAT], 11:0
ENDPTPRIME
Software sets a bit to instruct the controller to prepare for a
packet transfer. The QH, dTD’s, and endpoint registers are
ready.
Read and
Write-one-to-set.
[PETB], 27:16
(IN or Interrupt)
[PERB], 11:0
(OUT)
ENDPTFLUSH
Software sets a bit to instruct the controller to flush an
endpoint.
Read and
Write-one-to-set.
[FETB], 27:16 [FERB], 11:0
ENDPTSTAT
Indicates that the controller hardware has primed the endpoint
as requested by the ENDPTPRIME register.
Read-only.
[ETBR], 27:16 [ERBR], 11:0
ENDPTCOMPLETE
Indicates that the controller has completed the transfer that
was primed.
Read and
Write-one-to-clear.
[ETCE], 27:16 [ERCE], 11:0
