Chapter 15: USB Host, Device, and OTG Controller
siTD DWord 3: Transfer Status and Control
DWord 3 is used to manage the state of the split data transfer.
Status bits [7:0]
• Active Status [7]. Set to 1 by the HCD to enable the execution of an isochronous split
transaction by the Host Controller
• ERR Status [6]. Set to a 1 by the host controller when an ERR response is received from the
Companion Controller.
• Data Buffer Error Status [5]. Set to a 1 by the host controller during status update to indicate
that the host controller is unable to keep up with the reception of incoming data (overrun) or is
unable to supply data fast enough during transmission (under run). In the case of an under run,
the host controller will transmit an incorrect CRC (thus invalidating the data at the endpoint). If
an overrun condition occurs, no action is necessary.
• Babble Detected Status [4]. Set to 1 by the Host Controller during status update when 'babble'
is detected during the transaction generated by this descriptor.
• Transaction Error Status [3]. Set to 1 by the host controller during status update in the case
where the host did not receive a valid response from the device (Timeout, CRC, Bad PID, etc.).
This bit can only be set for isochronous IN transactions.
• Missed Microframe Status [2]. The host controller detected that a host-induced holdoff
caused the host controller to miss a required complete-split transaction.
• Split Transaction State Status [1].
- 0: Do Start Split. This value directs the host controller to issue a Start split transaction to
the endpoint when a match is encountered in the S-mask.
- 1: Do Complete Split. This value directs the host controller to issue a Complete split
transaction to the endpoint when a match is encountered in the C-mask.
• Reserved [0]. Bit reserved for future use and should be set to 0.
Table 15-32: USB Host siTD DWord 3: Transfer Status and Control
Bits Description
31 Interrupt On Complete, IOC.
• 0: Do not interrupt when transaction is complete
• 1: Do interrupt when transaction is complete
When the host controller determines that the split transaction has completed it will assert a hardware
interrupt at the next interrupt threshold.
30 Page Select, P. Used to indicate which data page pointer should be concatenated with the Current
Offset field to construct a data buffer pointer (0 selects Page 0 pointer and 1 selects Page 1). The host
controller is not required to write this field back when the siTD is retired (Active bit transitioned from
a 1 to a 0).
29:26 Reserved. Field reserved and should be set to 0.
25:16 Total Bytes To Transfer, Total Bytes. This field is initialized by the HCD to the total number of bytes
expected in this transfer. Maximum value is 1,023 (3FFh).
15:8 Microframe Complete-split Progress Mask, uFrame C prog-mask. This field is used by the host
controller to record which split-completes has been executed.
7:0 Status [7:0]. Refer to text.
