Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 477
UG585 (v1.11) September 27, 2016
Chapter 15: USB Host, Device, and OTG Controller
Table 15-50: USB ULPI Signals on MIO
USB Port Signals
MIO Pins Default
Input
Value to
Controller
USB 0 USB 1 I/O
Name
Transmit and receive data 4 28 40 IO USB{0,1}_ULPI_DATA4 ~
Data bus direction control 29 41 I USB{0,1}_ULPI_DIR 0
Stop the Transfer (end/interrupt) 30 42 O USB{0,1}_ULPI_STP ~
Data flow control signal 31 43 I USB{0,1}_ULPI_NXT 0
Transmit and receive data 0 32 44 IO USB{0,1}_ULPI_DATA0 ~
Transmit and receive data 1 33 45 IO USB{0,1}_ULPI_DATA1 ~
Transmit and receive data 2 34 46 IO USB{0,1}_ULPI_DATA2 ~
Transmit and receive data 3 35 47 IO USB{0,1}_ULPI_DATA3 ~
Transceiver clock for ULPI 36 48 I USB{0,1}_ULPI_CLK 0
Transmit and receive data 5 37 49 IO USB{0,1}_ULPI_DATA5 ~
Transmit and receive data 6 38 50 IO USB{0,1}_ULPI_DATA6 ~
Transmit and receive data 7 39 51 IO USB{0,1}_ULPI_DATA7 ~
Table 15-51: USB Port Indicator and Power Signals on EMIO
USB Port Signals
EMIO Signals Default
Input
Value to
Controller
Name
I/O
Port Indicator EMIOUSB{0,1}PORTINDCTL{0,1} O ~
Power Fault EMIOUSB{0,1}VBUSPWRFAULT I 0
Power Select EMIOUSB{0,1}VBUSPWRSELECT O ~
