Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 620
UG585 (v1.11) September 27, 2016
Chapter 21: Programmable Logic Description
°
Register and shift register functionality
°
Cascadable adders
•36KB block RAM
°
Dual port
°
Up to 72 bit-wide
°
Configurable as dual 18 KB
°
Programmable FIFO logic
°
Built-in error correction circuitry
• Digital signal processing – DSP48E1 Slice
°
25 × 18 two's complement multiplier/accumulator high-resolution 48-bit
multiplier/accumulator
°
Power saving 25-bit pre-adder to optimize symmetrical filter applications
°
Advanced features: optional pipelining, optional ALU, and dedicated buses for cascading
• Clock management
°
High-speed buffers and routing for low-skew clock distribution
°
Frequency synthesis and phase shifting
°
Low-jitter clock generation and jitter filtering
•Configurable I/Os
°
High-performance SelectIO technology
°
High-frequency decoupling capacitors within the package for enhanced signal integrity
°
Digitally controlled impedance that can be 3-stated for lowest power, high-speed I/O
operation
°
High-range (HR) I/O supporting 1.2V to 3.3V
°
High performance (HP) I/Os support 1.2V to 1.8V (7z030, 7z035, 7z045, and 7z100 devices)
• Low-power serial transceivers (7z012s, 7z015, 7z030, 7z035, 7z045 and 7z100 devices)
°
High-performance transceivers capable of up to 12.5 Gb/s (GTX) in 7z030, 7z035, 7z045, and
7z100 devices.
°
High-performance transceivers capable of up to 6.25 Gb/s (GTP) in 7z012s and 7z015
devices.
°
Low-power mode optimized for chip-to-chip interfaces
°
Advanced transmit pre and post emphasis, and receiver linear (CTLE) and decision feedback
equalization (DFE), including adaptive equalization for additional margin
• Integrated interface block for PCI Express designs
°
Compatible with the PCI Express Base Specification 2.1 with Endpoint and Root Port
capability
°
Supports Gen2 (5.0 Gb/s)
°
Advanced configuration options, advanced error reporting (AER), and end-to-end CRC
(ECRC) advanced error reporting and ECRC features
