Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 634
UG585 (v1.11) September 27, 2016
Chapter 21: Programmable Logic Description
XC7Z35-FBG676/FFG676 and XC7Z45-FBG676/FFG676 Package Placement Diagrams
Figure 21-4 shows the placement diagrams for the XC7Z35-FBG676/FFG676 and
XC7Z45-FBG676/FFG676 devices, MGT Bank 111.
X-Ref Target - Figure 21-4
Figure 21-4: XC7Z35-FBG676/FFG676 and XC7Z45-FBG676/FFG676 MGT Bank 111 Package Placement
Diagram
AD7 MGTXRXN0_111
AD8 MGTXRXP0_111
AF7 MGTXTXN0_111
AF8 MGTXTXP0_111
AE5 MGTXRXN1_111
UG585_C21_04_110514
AE6 MGTXRXP1_111
AF3 MGTXTXN1_111
AF4 MGTXTXP1_111
AC5 MGTXRXN2_111
AC6 MGTXRXP2_111
AE1 MGTXTXN2_111
AE2 MGTXTXP2_111
AD3 MGTXRXN3_111
AD4 MGTXRXP3_111
AC1 MGTXTXN3_111
AC2 MGTXTXP3_111
W5 MGTREFCLK0N_111
W6 MGTREFCLK0P_111
AA5 MGTREFCLK1N_111
AA6 MGTREFCLK1P_111
XC7Z35/XC7Z45-FBG676:
GTXE2_CHANNEL_X0Y0
XC7Z35/XC7Z45-FFG676:
GTXE2_CHANNEL_X0Y0
MGT_BANK_111
XC7Z35/XC7Z45-FBG676:
GTXE2_CHANNEL_X0Y1
XC7Z35/XC7Z45-FFG676:
GTXE2_CHANNEL_X0Y1
XC7Z35/XC7Z45-FBG676:
GTXE2_CHANNEL_X0Y2
XC7Z35/XC7Z45-FFG676:
GTXE2_CHANNEL_X0Y2
XC7Z35/XC7Z45-FBG676:
GTXE2_CHANNEL_X0Y3
XC7Z35/XC7Z45-FFG676:
GTXE2_CHANNEL_X0Y3
XC7Z35/XC7Z45-FBG676:
GTXE2_COMMON_X0Y0
XC7Z35/XC7Z45-FFG676:
GTXE2_COMMON_X0Y0
