Chapter 21: Programmable Logic Description
Figure 21-5 shows the placement diagram for the XC7Z35-FBG676/FFG676 and
XC7Z45-FBG676/FFG676 devices, MGT Bank 112.
X-Ref Target - Figure 21-5
Figure 21-5: XC7Z35-FBG676/FFG676 and XC7Z45-FBG676/FFG676 MGT Bank 112 Package Placement
Diagram
AB3 MGTXRXN0_112
AB4 MGTXRXP0_112
AA1 MGTXTXN0_112
AA2 MGTXTXP0_112
Y3 MGTXRXN1_112
UG585_C21_05_110514
Y4 MGTXRXP1_112
W1 MGTXTXN1_112
W2 MGTXTXP1_112
V3 MGTXRXN2_112
V4 MGTXRXP2_112
U1 MGTXTXN2_112
U2 MGTXTXP2_112
T3 MGTXRXN3_112
T4 MGTXRXP3_112
R1 MGTXTXN3_112
R2 MGTXTXP3_112
R5 MGTREFCLK0N_112
R6 MGTREFCLK0P_112
U5 MGTREFCLK1N_112
U6 MGTREFCLK1P_112
XC7Z35/XC7Z45-FBG676:
GTXE2_CHANNEL_X0Y4
XC7Z35/XC7Z45-FFG676:
GTXE2_CHANNEL_X0Y4
MGT_BANK_112
XC7Z35/XC7Z45-FBG676:
GTXE2_CHANNEL_X0Y5
XC7Z35/XC7Z45-FFG676:
GTXE2_CHANNEL_X0Y5
XC7Z35/XC7Z45-FBG676:
GTXE2_CHANNEL_X0Y6
XC7Z35/XC7Z45-FFG676:
GTXE2_CHANNEL_X0Y6
XC7Z35/XC7Z45-FBG676:
GTXE2_CHANNEL_X0Y7
XC7Z35/XC7Z45-FFG676:
GTXE2_CHANNEL_X0Y7
XC7Z35/XC7Z45-FBG676:
GTXE2_COMMON_X0Y0
XC7Z35/XC7Z45-FFG676:
GTXE2_COMMON_X0Y0
