Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 636
UG585 (v1.11) September 27, 2016
Chapter 21: Programmable Logic Description
XC7Z35-FFG900, XC7Z45-FFG900, and XC7Z100-FFG900 Package Placement Diagram
Figure 21-6 shows the placement diagram for the XC7Z35-FFG900, XC7Z45-FFG900, and
XC7Z100-FFG900 devices, MGT Bank 109.
X-Ref Target - Figure 21-6
Figure 21-6: XC7Z35-FFG900, XC7Z45-FFG900, and XC7Z100-FFG900, MGT Bank 109 Package Placement
Diagram
AH9 MGTXRXN0_109
AH10 MGTXRXP0_109
AK9 MGTXTXN0_109
AK10 MGTXTXP0_109
AJ7 MGTXRXN1_109
UG585_C21_06_110514
AJ8 MGTXRXP1_109
AK5 MGTXTXN1_109
AK6 MGTXTXP1_109
AG7 MGTXRXN2_109
AG8 MGTXRXP2_109
AJ3 MGTXTXN2_109
AJ4 MGTXTXP2_109
AE7 MGTXRXN3_109
AE8 MGTXRXP3_109
AK1 MGTXTXN3_109
AK2 MGTXTXP3_109
AD9 MGTREFCLK0N_109
AD10 MGTREFCLK0P_109
AF9 MGTREFCLK1N_109
AF10 MGTREFCLK1P_109
XC7Z35/XC7Z45/XC7Z100-FFG900:
GTXE2_CHANNEL_X0Y0
MGT_BANK_109
XC7Z35/XC7Z45/XC7Z100-FFG900:
GTXE2_CHANNEL_X0Y1
XC7Z35/XC7Z45/XC7Z100-FFG900:
GTXE2_CHANNEL_X0Y2
XC7Z35/XC7Z45/XC7Z100-FFG900:
GTXE2_CHANNEL_X0Y3
XC7Z35/XC7Z45/XC7Z100-FFG900:
GTXE2_COMMON_X0Y0
