Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 639
UG585 (v1.11) September 27, 2016
Chapter 21: Programmable Logic Description
Figure 21-9 shows the placement diagram for the XC7Z35-FFG900, XC7Z45-FFG900, and
XC7Z100-FFG900 devices, MGT Bank 112.
X-Ref Target - Figure 21-9
Figure 21-9: XC7Z35-FFG900, XC7Z45-FFG900, and XC7Z100-FFG900, MGT Bank 112 Package Placement
Diagram
V5 MGTXRXN0_112
V6 MGTXRXP0_112
T1 MGTXTXN0_112
T2 MGTXTXP0_112
U3 MGTXRXN1_112
UG585_C21_09_110514
U4 MGTXRXP1_112
R3 MGTXTXN1_112
R4 MGTXTXP1_112
T5 MGTXRXN2_112
T6 MGTXRXP2_112
P1 MGTXTXN2_112
P2 MGTXTXP2_112
P5 MGTXRXN3_112
P6 MGTXRXP3_112
N3 MGTXTXN3_112
N4 MGTXTXP3_112
N7 MGTREFCLK0N_112
N8 MGTREFCLK0P_112
R7 MGTREFCLK1N_112
R8 MGTREFCLK1P_112
XC7Z35/XC7Z45/XC7Z100-FFG900:
GTXE2_CHANNEL_X0Y12
MGT_BANK_112
XC7Z35/XC7Z45/XC7Z100-FFG900:
GTXE2_CHANNEL_X0Y13
XC7Z35/XC7Z45/XC7Z100-FFG900:
GTXE2_CHANNEL_X0Y14
XC7Z35/XC7Z45/XC7Z100-FFG900:
GTXE2_CHANNEL_X0Y15
XC7Z35/XC7Z45/XC7Z100-FFG900:
GTXE2_COMMON_X0Y0
