Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 640
UG585 (v1.11) September 27, 2016
Chapter 21: Programmable Logic Description
XC7Z100-FFG1156 Package Placement Diagram
Figure 21-10 shows the placement diagram for the XC7Z100-FFG1156 device, MGT Bank 109.
X-Ref Target - Figure 21-10
Figure 21-10: XC7Z100-FFG1156, MGT Bank 109 Package Placement Diagram
AN7 MGTXRXN0_109
AN8 MGTXRXP0_109
AP1 MGTXTXN0_109
AP2 MGTXTXP0_109
AP5 MGTXRXN1_109
UG585_C21_10_090914
AP6 MGTXRXP1_109
AM1 MGTXTXN1_109
AM2 MGTXTXP1_109
AM5 MGTXRXN2_109
AM6 MGTXRXP2_109
AL3 MGTXTXN2_109
AL4 MGTXTXP2_109
AN3 MGTXRXN3_109
AN4 MGTXRXP3_109
AK1 MGTXTXN3_109
AK2 MGTXTXP3_109
AJ7 MGTREFCLK0N_109
AJ8 MGTREFCLK0P_109
AL7 MGTREFCLK1N_109
AL8 MGTREFCLK1P_109
XC7Z100-FFG1156:
GTXE2_CHANNEL_X0Y0
MGT_BANK_109
XC7Z100-FFG1156:
GTXE2_CHANNEL_X0Y1
XC7Z100-FFG1156:
GTXE2_CHANNEL_X0Y2
XC7Z100-FFG1156:
GTXE2_CHANNEL_X0Y3
XC7Z100-FFG1156:
GTXE2_COMMON_X0Y0
