Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 643
UG585 (v1.11) September 27, 2016
Chapter 21: Programmable Logic Description
Figure 21-13 shows the placement diagram for the XC7Z100-FFG1156 device, MGT Bank 112.
X-Ref Target - Figure 21-13
Figure 21-13: XC7Z100-FFG1156, MGT Bank 112 Package Placement Diagram
W3 MGTXRXN0_112
W4 MGTXRXP0_112
V1 MGTXTXN0_112
V2 MGTXTXP0_112
V5 MGTXRXN1_112
UG585_C21_13_090914
V6 MGTXRXP1_112
T1 MGTXTXN1_112
T2 MGTXTXP1_112
U3 MGTXRXN2_112
U4 MGTXRXP2_112
R3 MGTXTXN2_112
R4 MGTXTXP2_112
T5 MGTXRXN3_112
T6 MGTXRXP3_112
P1 MGTXTXN3_112
P2 MGTXTXP3_112
R7 MGTREFCLK0N_112
R8 MGTREFCLK0P_112
U7 MGTREFCLK1N_112
U8 MGTREFCLK1P_112
XC7Z100-FFG1156:
GTXE2_CHANNEL_X0Y12
MGT_BANK_112
XC7Z100-FFG1156:
GTXE2_CHANNEL_X0Y13
XC7Z100-FFG1156:
GTXE2_CHANNEL_X0Y14
XC7Z100-FFG1156:
GTXE2_CHANNEL_X0Y15
XC7Z100-FFG1156:
GTXE2_COMMON_X0Y0
