Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 659
UG585 (v1.11) September 27, 2016
Chapter 22: Programmable Logic Design Guide
For more information on S_ACI_ACP, see Chapter 3, Application Processing Unit. See Chapter 29,
On-Chip Memory (OCM) when using ACP with OCM.
22.4.6 PL DMA via General Purpose AXI Slave (GP)
While the general purpose AXI Slave (S_AXI_GP) has reasonably low latency to OCM and DDR, its
narrow 32-bit interface limits its utility as a DMA interface. The two S_AXI_GP interfaces are more
likely to be used for lower-performance control access to the PS memories, registers and peripherals.
More information on the S_AXI_GP interfaces can be found in Chapter 5, Interconnect.
X-Ref Target - Figure 22-4
Figure 22-4: Example ACP DMA Topology
PCIe
GTX or
GTP
NOTE: GigaBit Transceiver and PCIe
functionality are not available in
all device versions
and packages.
IRQ
L2
Cache Memory
512 KB
DDR
Memory
Controller
16-bit
32-bit
16-bit w/ECC
DMA
8 channel
PCAP
Processor Config
Access Port
M_AXI_GP x 2
General Purpose
32-bit AXI Master
S_AXI_GP x 2
General Purpose
32-bit AXI Slave
S_AXI_HP x 4
AXI Data
32/64-bit Slave
SCU – Snoop Control Unit
Central
Interconnect
ARM A9
32 KB I-Cache
32 KB D-Cache
NEON
SP, DP FPU
128-bit Vector DSP
OCM
On Chip Memory
256 KB
S_AXI_ACP
AXI Coherent
64-bit Slave
Mem Switch
SLCR
System Level
Control
Registers
Security
Config
XADC
16 ch ADC
Block RAM
DMA
User
IP
Control
I/O Interface
Quad-SPI
1,2,4,8-bit
Parallel 8-bit
NOR/SRAM
NAND 8,16-bit
UART
UART
SPI
SPI
I2C
I2C
CAN
CAN
TTC/SWDT
PJTAG
Reset
CLK / PLL
ARM, I/O, DDR
PS_POR_B
PS_SRST_B
PS_CLK
DDR
Coresight
Trace In
Trace Out
Cross Trigger
DAP
APB
Register Access
Processing
System (PS)
EMIO
USB
USB
GigE
GigE
SD
SD
DMA
DMA
DMA
DMA
DMA
DMA
GPIO x54, x64
MIO
Pins
NEON
SP, DP FPU
128-bit Vector DSP
ARM A9
32 KB I-Cache
32 KB D-Cache
UG585_c22_06_102414
Programmable
Logic (PL)
