Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 670
UG585 (v1.11) September 27, 2016
Chapter 24
Power Management
24.1 Introduction
Power optimization can start with selecting the right Zynq-7000 AP SoC device. For low-power
applications, choose either the 7z010 or 7z020 dual core device or the 7z007s, 7z012s, or 7z014s
single core device. Power can dramatically be reduced by shutting-down the PL side of the device.
I/O voltage and termination choice also affects power consumption. The clocks to individual PS
subsystems can be stopped.
The functionality of the PS is the same for all Zynq-7000 AP SoC devices except that the 7z012s and
7z015 devices have a reduced MIO pin count which impacts the availability of the Ethernet, USB and
other controllers. The two Zynq data sheets describe the clock frequency differences. The PL resource
differences for each device type are shown in section 21.1.2 PL Resources by Device Type.
Detailed device level power estimates for the PS and PL can be obtained using the XPE power
estimator spreadsheet. Power specifications are found in the Zynq-7000 AP SoC device datasheets
(see Appendix A, Additional Resources for a list of related documents).
24.1.1 Features
Key system power management features are as follows.
• Choose between device technology:
°
7z010 and 7z020 dual core or 7z007s, 7z012s, or 7z014s single core (derived from Artix AP
FPGA technology)
°
7z030, 7z035, 7z045, and 7z100 (derived from Kintex AP FPGA technology)
•PL power-off
• Cortex A9 processor standby mode
• Clock gating for most PS subsystems
• Three PLLs can be programmed to minimize power consumption
• Subsystem clocks can be programmed for optional clock frequency
• Programmable voltage for I/O Banks:
°
MIO: HSTL 1.8V, LVCMOS 1.8V, 2.5V and 3.3V
°
DDR: DDR2 1.8V, DDR3 1.5V and LPDDR2 1.2V
• DDR3 and LPDDR2 low power mode
