Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 708
UG585 (v1.11) September 27, 2016
Chapter 26: Reset System
DDR DDR PHY/controller/control registers slcr.DDR_RST_CTRL
DMA DMA interface slcr.DMAC_RST_CTRL
Ethernet Ref, Rx and CPU 1x slcr.GEM_RST_CTRL
PS–PL General purpose PL resets slcr.FPGA_RST_CTRL
GPIO CPU 1x slcr.GPIO_RST_CTRL
I2C CPU 1x slcr.I2C_RST_CTRL
Quad-SPI Ref and CPU 1x slcr.LQSPI_RST_CTRL
SDIO Ref and CPU 1x slcr.SDIO_RST_CTRL
SPI Ref and CPU 1x slcr.SPI_RST_CTRL
SMC Ref and CPU 1x slcr.SMC_RST_CTRL
UART Ref and CPU 1x slcr.UART_RST_CTRL
USB ULPI and CPU 1x slcr.USB_RST_CTRL
Table 26-4: Peripheral Reset Control Registers Overview (Cont’d)
Peripheral Name Description HW Register
