Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 719
UG585 (v1.11) September 27, 2016
Chapter 27: JTAG and DAP Subsystem
ISC_PROGRAM
010001
Enables in-system programming
ISC_PROGRAM_SECURITY
010010
Change security status from secure to non-secure
mode and vice versa
ISC_NOOP
010100
No operation
ISC_READ
101011
Used to read back BBR
ISC_DISABLE
010111
Completes ISC configuration. Startup sequence is
executed
BYPASS
111111
Enables bypass
Table 27-6: JTAG Commands (Cont’d)
Boundary Scan Command Binary Code[5:0] Description
