Chapter 28: System Test and Debug
Trigger input 1 FTM trigger
Trigger input 2 FTM trigger
Trigger input 3 FTM trigger
Trigger output 0 FTM trigger
Trigger output 1 FTM trigger
Trigger output 2 FTM trigger
Trigger output 3 FTM trigger
CTI (connected to CPU0)
Trigger input 0 CPU0 DBGACK
Trigger input 1 CPU0 PMU IRQ
Trigger input 2 PTM0 EXT
Trigger input 3 PTM0 EXT
Trigger input 4 CPU0 COMMTX
Trigger input 5 CPU0 COMMRX
Trigger input 6 PTM0 TRIGGER
Trigger output 0 CPU0 debug request
Trigger output 1 PTM0 EXT
Trigger output 2 PTM0 EXT
Trigger output 3 PTM0 EXT
Trigger output 4 PTM0 EXT
Trigger output 7 CPU0 restart request
CTI (connected to CPU1)
Trigger input 0 CPU1 DBGACK
Trigger input 1 CPU1 PMU IRQ
Trigger input 2 PTM1 EXT
Trigger input 3 PTM1 EXT
Trigger input 4 CPU1 COMMTX
Trigger input 5 CPU1 COMMRX
Trigger input 6 PTM1 TRIGGER
Trigger output 0 CPU1 debug request
Trigger output 1 PTM1 EXT
Trigger output 2 PTM1 EXT
Trigger output 3 PTM1 EXT
Trigger output 4 PTM1 EXT
Trigger output 7 CPU1 restart request
Table 28-1: CTI Trigger Inputs and Outputs (Cont’d)
CTI Trigger Port Signal
