Chapter 28: System Test and Debug
CoreSight management Peripheral ID
Component ID
Device ID, type
Claim, lock, authentication
Integration test
These registers provide:
• Identification information
• Authentication and access control
• Integration test
TPIU
Supported feature Show maximum and current values of supported port size,
test patterns, etc.
Trigger Set Trigger counter, multiplier
Testing Set test pattern, modes and repeat count
Format and finish Control and status of formatter and flush
CoreSight management Peripheral ID
Component ID
Device ID, type
Claim, lock, authentication
Integration test
These registers provide:
• Identification information
• Authentication and access control
• Integration test
Funnel
Control Control, Priority Enable slave ports, set hold time, and priority
CoreSight management Peripheral ID
Component ID
Device ID, type
Claim, lock, authentication
Integration test
These registers provide:
• Identification information
• Authentication and access control
• Integration test
ITM
Control CR, SCR Enable ITM, configure features like timestamp, sync packets,
sync count, etc.
Stimulus SPR Cause the write data to be inserted into the FIFO for packets
Trace TER, TTR Enable trace and trigger
CoreSight management Peripheral ID
Component ID
Device ID, type
Claim, lock, authentication
Integration test
These registers provide:
• Identification information
• Authentication and access control
• Integration test
FTM
Cortex-A9 Integration ROM
Pointers Entry Pointers to other CoreSight components for A9
CoreSight management Peripheral ID
Component ID
These registers provide identification information
CPU debug
Table 28-6: CoreSight Component Register Summary (Cont’d)
Function Name Overview
