Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 785
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
50 modules, 2036 registers.
gem1 GEM 0xE000C000 Gigabit Ethernet Controller
gpio gpio
0xE000A000 General Purpose Input / Output
gpv_qos301_c
pu
qos301
0xF8946000 AMBA Network Interconnect Advanced Quality of
Service (QoS-301), CPU-to-DDR
gpv_qos301_d
mac
qos301
0xF8947000 AMBA Network Interconnect Advanced Quality of
Service (QoS-301), DMAC
gpv_qos301_io
u
qos301
0xF8948000 AMBA Network Interconnect Advanced Quality of
Service (QoS-301), IOU
gpv_trustzone nic301_addr_r
egion_ctrl_regi
sters
0xF8900000 AMBA NIC301 TrustZone.
i2c0 IIC
0xE0004000 Inter Integrated Circuit (I2C)
i2c1 IIC
0xE0005000 Inter Integrated Circuit (I2C)
l2cache L2Cpl310
0xF8F02000 L2 cache PL310
mpcore mpcore
0xF8F00000 Mpcore - SCU, Interrupt controller, Counters and Timers
ocm ocm
0xF800C000 On-Chip Memory Registers
qspi qspi
0xE000D000 LQSPI module Registers
sd0 sdio
0xE0100000 SD2.0/ SDIO2.0/ MMC3.31 AHB Host
ControllerRegisters
sd1 sdio
0xE0101000 SD2.0/ SDIO2.0/ MMC3.31 AHB Host
ControllerRegisters
slcr slcr
0xF8000000 System Level Control Registers
smcc pl353
0xE000E000 Shared memory controller
spi0 SPI
0xE0006000 Serial Peripheral Interface
spi1 SPI
0xE0007000 Serial Peripheral Interface
swdt swdt
0xF8005000 System Watchdog Timer Registers
ttc0 ttc
0xF8001000 Triple Timer Counter
ttc1 ttc
0xF8002000 Triple Timer Counter
uart0 UART
0xE0000000 Universal Asynchronous Receiver Transmitter
uart1 UART
0xE0001000 Universal Asynchronous Receiver Transmitter
usb0 usb
0xE0002000 USB controller registers
usb1 usb
0xE0003000 USB controller registers
Module Name Module Type Base Address Description
