Appendix B: Register Details
Register AFI_RDQOS Details
Sets the static Qos value to be used for the read channel. If APB register field, 'FabricQosEn' is 0 or
('FabricQosEn' is 1 and 'QosHeadOfCmdQEn' is 1), this static Qos value will be applied to all read
commands enqueued into the RdCmdQ. If ('FabricQosEn' is 1 and 'QosHeadOfCmdQEn' is 0), this static
Qos field will be ignored. The associated "FPGA_RST_CTRL.FPGA_AXDSN_RST" register field
must be written with "0" before accessing this register
Register (axi_hp) AFI_RDDATAFIFO_LEVEL
Register AFI_RDDATAFIFO_LEVEL Details
Returns the Level of the Read Data FIFO in Qwords. Note that this register should only be read if a valid
HP port clock is actively running. If no clock is running the APB access will hang. The associated
"FPGA_RST_CTRL.FPGA_AXDSN_RST" register field
must be written with "0" before accessing this register
Field Name Bits Type Reset Value Description
reserved 31:4 raz 0x0 Return 0 when read
staticQos 3:0 rw 0x0 Sets the level of the Qos field to be used for the
read channel
4'b0000: Lowest Priority' ' '4'b1111: Highest
Priority
Name AFI_RDDATAFIFO_LEVEL
Relative Address 0x0000000C
Absolute Address axi_hp0: 0xF800800C
axi_hp1: 0xF800900C
axi_hp2: 0xF800A00C
axi_hp3: 0xF800B00C
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description Read Data FIFO Level Register
Field Name Bits Type Reset Value Description
reserved 31:8 raz 0x0 Return 0 when read
FifoLevel 7:0 ro 0x0 Returns the level measured in Dwords (64-bits) of
the Read Data FIFO
8'h00: 0 Entries
8'h01: 1 Entry' ' '8'h8F: 128 Entries
