Appendix B: Register Details
Register (axi_hp) AFI_WRQOS
Register AFI_WRQOS Details
Sets the static Qos value to be used for the write channel. If APB register field, 'FabricQosEn' is 0 or
('FabricQosEn' is 1 and 'QosHeadOfCmdQEn' is 1), this static Qos value will be applied to all write
commands enqueued into the WrCmdQ. If ('FabricQosEn' is 1 and 'QosHeadOfCmdQEn' is 0), this static
Qos field will be ignored. The associated "FPGA_RST_CTRL.FPGA_AXDSN_RST" register field
must be written with "0" before accessing this register
Field Name Bits Type Reset Value Description
reserved 31:7 raz 0x0 Return 0 when read
wrIssueCap1 6:4 rw 0x0 Max number of outstanding write commands
(Write Issuing Capability) field 1:
3'b000: 1 command
3'b001: 2 commands' ' '3'b111: 8 commands
reserved 3 raz 0x0 Return 0 when read
wrIssueCap0 2:0 rw 0x7 Max number of outstanding write commands
(Write Issuing Capability) field 0:
3'b000: 1 command
3'b001: 2 commands' ' '3'b111: 8 commands
Name AFI_WRQOS
Relative Address 0x0000001C
Absolute Address axi_hp0: 0xF800801C
axi_hp1: 0xF800901C
axi_hp2: 0xF800A01C
axi_hp3: 0xF800B01C
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description QOS Write Channel Register
Field Name Bits Type Reset Value Description
reserved 31:4 raz 0x0 Return 0 when read
staticQos 3:0 rw 0x0 Sets the level of the Qos field to be used for the
write channel
4'b0000: Lowest Priority' ' '4'b1111: Highest
Priority
