Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 799
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (can) BRPR
Register BRPR Details
The BRPR can be programmed to any value in the range 0-255. The actual value is 1 more than the value
written into the register.
Please refer to the CAN chapter for more details.
Field Name Bits Type Reset Value Description
reserved 31:3 rw 0x0 Reserved.
SNOOP 2 rw 0x0 Snoop Mode Select
The Snoop Mode Select bit.
1: CAN controller is in Snoop mode.
0: CAN controller is in Normal, Loop Back,
Configuration, or Sleep mode.
This bit can be written to only when CEN bit in
SRR is 0.
LBACK 1 rw 0x0 Loop Back Mode Select
The Loop Back Mode Select bit.
1: CAN controller is in Loop Back mode.
0: CAN controller is in Normal, Snoop,
Configuration, or Sleep mode.
This bit can be written to only when CEN bit in
SRR is 0.
SLEEP 0 rw 0x0 Sleep Mode Select
The Sleep Mode select bit.
1: CAN controller is in Sleep mode.
0: CAN controller is in Normal, Snoop,
Configuration or Loop Back mode.
This bit is cleared when the CAN controller wakes
up from the Sleep mode.
Name BRPR
Relative Address 0x00000008
Absolute Address can0: 0xE0008008
can1: 0xE0009008
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description Baud Rate Prescaler Register
