Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 802
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register ESR Details
The Error Status Register (ESR) indicates the type of error that has occurred on the bus. If more than one
error occurs, all relevant error flag bits are set in this register. The ESR is a write-to-clear register. Writes to
this register will not set any bits, but will clear the bits that are set.
Reset Value 0x00000000
Description Error Status Register
Field Name Bits Type Reset Value Description
reserved 31:5 rw 0x0 Reserved
ACKER 4 wtc 0x0 ACK Error
Indicates an acknowledgment error.
1: Indicates an acknowledgment error has
occurred.
0: Indicates an acknowledgment error has not
occurred on the bus since the last write to this
register.
If this bit is set, writing a 1 clears it.
BERR 3 wtc 0x0 Bit Error
Indicates the received bit is not the same as the
transmitted bit during bus communication.
1: Indicates a bit error has occurred.
0: Indicates a bit error has not occurred on the bus
since the last write to this register.
If this bit is set, writing a 1 clears it.
STER 2 wtc 0x0 Stuff Error
Indicates an error if there is a stuffing violation.
1: Indicates a stuff error has occurred.
0: Indicates a stuff error has not occurred on the
bus since the last write to this register.
If this bit is set, writing a 1 clears it.
