Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 806
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Field Name Bits Type Reset Value Description
reserved 31:15 rw 0x0 reserved
TXFEMP
(IXR_TXFEMP)
14 ro 0x1 Transmit FIFO EmptyInterrupt
A 1 indicates that the Transmit FIFO is empty.
The interrupt continues to assert as long as the TX
FIFO is empty.
This bit can be cleared only by writing to the ICR.
TXFWMEMP
(IXR_TXFWMEMP)
13 ro 0x1 Transmit FIFO Watermark Empty Interrupt
A 1 indicates that the TX FIFO is empty based on
watermark programming.
The interrupt continues to assert as long as the
number of empty spaces in the TX FIFO is greater
than TX FIFO empty watermark.
This bit can be cleared only by writing to the
Interrupt Clear Register.
RXFWMFLL
(IXR_RXFWMFLL)
12 ro 0x0 Receive FIFO Watermark Full Interrupt
A 1 indicates that the RX FIFO is full based on
watermark programming.
The interrupt continues to assert as long as the RX
FIFO count is above RX FIFO Full watermark.
This bit can be cleared only by writing to the
Interrupt Clear Register.
WKUP
(IXR_WKUP)
11 ro 0x0 Wake up Interrupt
A 1 indicates that the CAN controller entered
Normal mode from Sleep Mode.
This bit can be cleared by writing to the ICR.
This bit is also cleared when a 0 is written to the
CEN bit in the SRR.
SLP
(IXR_SLP)
10 ro 0x0 Sleep Interrupt
A 1 indicates that the CAN controller entered
Sleep mode.
This bit can be cleared by writing to the ICR.
This bit is also cleared when a 0 is written to the
CEN bit in the SRR.
BSOFF
(IXR_BSOFF)
9ro0x0 Bus Off Interrupt
A 1 indicates that the CAN controller entered the
Bus Off state.
This bit can be cleared by writing to the ICR.
This bit is also cleared when a 0 is written to the
CEN bit in the SRR.
