Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 807
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
ERROR
(IXR_ERROR)
8 ro 0x0 Error Interrupt
A 1 indicates that an error occurred during
message transmission or reception.
This bit can be cleared by writing to the ICR.
This bit is also cleared when a 0 is written to the
CEN bit in the SRR.
RXNEMP
(IXR_RXNEMP)
7 ro 0x0 Receive FIFO Not Empty Interrupt
A 1 indicates that the Receive FIFO is not empty.
This bit can be cleared only by writing to the ICR.
RXOFLW
(IXR_RXOFLW)
6 ro 0x0 RX FIFO Overflow Interrupt
A 1 indicates that a message has been lost. This
condition occurs when a new message is being
received and the Receive FIFO is Full.
This bit can be cleared by writing to the ICR.
This bit is also cleared when a 0 is written to the
CEN bit in the SRR.
RXUFLW
(IXR_RXUFLW)
5 ro 0x0 RX FIFO Underflow Interrupt
A 1 indicates that a read operation was attempted
on an empty RX FIFO.
This bit can be cleared only by writing to the ICR.
RXOK
(IXR_RXOK)
4 ro 0x0 New Message Received Interrupt
A 1 indicates that a message was received
successfully and stored into the RX FIFO.
This bit can be cleared by writing to the ICR.
This bit is also cleared when a 0 is written to the
CEN bit in the SRR.
TXBFLL
(IXR_TXBFLL)
3 ro 0x0 High Priority Transmit Buffer Full Interrupt
A 1 indicates that the High Priority Transmit
Buffer is full.
The status of the bit is unaffected if write
transactions occur on the High Priority Transmit
Buffer when it is already full.
This bit can be cleared only by writing to the ICR.
TXFLL
(IXR_TXFLL)
2 ro 0x0 Transmit FIFO Full Interrupt
A 1 indicates that the TX FIFO is full.
The status of the bit is unaffected if write
transactions occur on the Transmit FIFO when it is
already full.
This bit can be cleared only by writing to the
Interrupt Clear Register.
Field Name Bits Type Reset Value Description
