Appendix B: Register Details
ETXFWMEMP
(IXR_TXFWMEMP)
13 rw 0x0 Enable TXFIFO watermark Empty Interrupt
Writes to this bit enable or disable interrupts
when the TXFWMEMP bit in the ISR is set.
1: Enable interrupt generation if TXFWMEMP bit
in ISR is set.
0: Disable interrupt generation if TXFWMEMP bit
in ISR is set.
ERXFWMFLL
(IXR_RXFWMFLL)
12 rw 0x0 Enable RXFIFO watermark Full Interrupt
Writes to this bit enable or disable interrupts
when the RXFLL bit in the ISR is set.
1: Enable interrupt generation if RXFWMFLL bit
in ISR is set.
0: Disable interrupt generation if RXFWMFLL bit
in ISR is set.
EWKUP
(IXR_WKUP)
11 rw 0x0 Enable Wake up Interrupt
Writes to this bit enable or disable interrupts
when the WKUP bit in the ISR is set.
1: Enable interrupt generation if WKUP bit in ISR
is set.
0: Disable interrupt generation if WKUP bit in ISR
is set.
ESLP
(IXR_SLP)
10 rw 0x0 Enable Sleep Interrupt
Writes to this bit enable or disable interrupts
when the SLP bit in the ISR is set.
1: Enable interrupt generation if SLP bit in ISR is
set.
0: Disable interrupt generation if SLP bit in ISR is
set.
EBSOFF
(IXR_BSOFF)
9 rw 0x0 Enable Bus OFF Interrupt
Writes to this bit enable or disable interrupts
when the BSOFF bit in the ISR is set.
1: Enable interrupt generation if BSOFF bit in ISR
is set.
0: Disable interrupt generation if BSOFF bit in ISR
is set.
EERROR
(IXR_ERROR)
8 rw 0x0 Enable Error Interrupt
Writes to this bit enable or disable interrupts
when the ERROR bit in the ISR is set.
1: Enable interrupt generation if ERROR bit in ISR
is set.
0: Disable interrupt generation if ERROR bit in
ISR is set.
Field Name Bits Type Reset Value Description
