Appendix B: Register Details
Register (can) ICR
Register ICR Details
ETXOK
(IXR_TXOK)
1 rw 0x0 Enable Transmission Successful Interrupt
Writes to this bit enable or disable interrupts
when the TXOK bit in the ISR is set.
1: Enable interrupt generation if TXOK bit in ISR
is set.
0: Disable interrupt generation if TXOK bit in ISR
is set.
EARBLST
(IXR_ARBLST)
0 rw 0x0 Enable Arbitration Lost Interrupt
Writes to this bit enable or disable interrupts
when the ARBLST bit in the ISR is set.
1: Enable interrupt generation if ARBLST bit in
ISR is set.
0: Disable interrupt generation if ARBLST bit in
ISR is set.
Name ICR
Relative Address 0x00000024
Absolute Address can0: 0xE0008024
can1: 0xE0009024
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description Interrupt Clear Register
Field Name Bits Type Reset Value Description
Field Name Bits Type Reset Value Description
reserved 31:15 rw 0x0 Reserved
CTXFEMP
(IXR_TXFEMP)
14 wo 0x0 Clear TXFIFO Empty Interrupt
Writing a 1 to this bit clears the TXFEMP bit in the
ISR.
CTXFWMEMP
(IXR_TXFWMEMP)
13 wo 0x0 Clear TXFIFO Watermark Empty Interrupt
Writing a 1 to this bit clears the TXFWMEMP bit
in the ISR.
CRXFWMFLL
(IXR_RXFWMFLL)
12 wo 0x0 Clear RXFIFO Watermark Full Interrupt
Writing a 1 to this bit clears the RXFWMFLL bit in
the ISR.
