Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 812
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (can) TCR
CWKUP
(IXR_WKUP)
11 wo 0x0 Clear Wake up Interrupt
Writing a 1 to this bit clears the WKUP bit in the
ISR.
CSLP
(IXR_SLP)
10 wo 0x0 Clear Sleep Interrupt
Writing a 1 to this bit clears the SLP bit in the ISR.
CBSOFF
(IXR_BSOFF)
9 wo 0x0 Clear Bus Off Interrupt
Writing a 1 to this bit clears the BSOFF bit in the
ISR.
CERROR
(IXR_ERROR)
8 wo 0x0 Clear Error Interrupt
Writing a 1 to this bit clears the ERROR bit in the
ISR.
CRXNEMP
(IXR_RXNEMP)
7 wo 0x0 Clear Receive FIFO Not Empty Interrupt
Writing a 1 to this bit clears the RXNEMP bit in the
ISR.
CRXOFLW
(IXR_RXOFLW)
6 wo 0x0 Clear RX FIFO Overflow Interrupt
Writing a 1 to this bit clears the RXOFLW bit in the
ISR.
CRXUFLW
(IXR_RXUFLW)
5 wo 0x0 Clear RX FIFO Underflow Interrupt
Writing a 1 to this bit clears the RXUFLW bit in the
ISR.
CRXOK
(IXR_RXOK)
4 wo 0x0 Clear New Message Received Interrupt
Writing a 1 to this bit clears the RXOK bit in the
ISR.
CTXBFLL
(IXR_TXBFLL)
3wo0x0 Clear High Priority Transmit Buffer Full Interrupt
Writing a 1 to this bit clears the TXBFLL bit in the
ISR.
CTXFLL
(IXR_TXFLL)
2 wo 0x0 Clear Transmit FIFO Full Interrupt
Writing a 1 to this bit clears the TXFLL bit in the
ISR.
CTXOK
(IXR_TXOK)
1 wo 0x0 Clear Transmission Successful Interrupt
Writing a 1 to this bit clears the CTXOK bit in the
ISR.
CARBLST
(IXR_ARBLST)
0 wo 0x0 Clear Arbitration Lost Interrupt
Writing a 1 to this bit clears the ARBLST bit in the
ISR.
Name TCR
Relative Address 0x00000028
Field Name Bits Type Reset Value Description
