Appendix B: Register Details
Register (can) TXFIFO_ID
Register TXFIFO_ID Details
Field Name Bits Type Reset Value Description
reserved 31:16 rw 0x0 reserved
EW 15:8 rw 0x3F TXFIFO Empty watermark
TXFIFO generates an EMPTY interrupt based on
the value programmed in this field. The valid
range is (1-63). No protection is given for illegal
programming in this field. This field can be
written to only when CEN bit in SRR is 0.
FW 7:0 rw 0x3F RXFIFO Full watermark
RXFIFO generates FULL interrupt based on the
value programmed in this field. The valid range is
(1-63). No protection is given for illegal
programming in this field. This field can be
written to only when CEN bit in SRR is 0.
Name TXFIFO_ID
Relative Address 0x00000030
Absolute Address can0: 0xE0008030
can1: 0xE0009030
Width 32 bits
Access Type wo
Reset Value 0x00000000
Description transmit message fifo message identifier
Field Name Bits Type Reset Value Description
IDH
(IDR_ID1)
31:21 wo 0x0 Standard Message ID
The Identifier portion for a Standard Frame is 11
bits. These bits indicate the Standard Frame ID.
This field is valid for both Standard and Extended
Frames.
SRRRTR
(IDR_SRR)
20 wo 0x0 Substitute Remote Transmission Request
This bit differentiates between data frames and
remote frames. Valid only for Standard Frames.
For Extended frames this bit is 1.
1: Indicates that the message frame is a Remote
Frame.
0: Indicates that the message frame is a Data
Frame.
