Appendix B: Register Details
Register (can) TXFIFO_DLC
Register TXFIFO_DLC Details
IDE
(IDR_IDE)
19 wo 0x0 Identifier Extension
This bit differentiates between frames using the
Standard Identifier and those using the Extended
Identifier. Valid for both Standard and Extended
Frames.
1: Indicates the use of an Extended Message
Identifier.
0: Indicates the use of a Standard Message
Identifier.
IDL
(IDR_ID2)
18:1 wo 0x0 Extended Message ID
This field indicates the Extended Identifier. Valid
only for Extended Frames. For Standard Frames,
reads from this field return 0s. For Standard
Frames, writes to this field should be 0s.
RTR
(IDR_RTR)
0 wo 0x0 Remote Transmission Request
This bit differentiates between data frames and
remote frames. Valid only for Extended Frames.
1: Indicates the message object is a Remote Frame
0: Indicates the message object is a Data Frame
For Standard Frames, reads from this bit returns 0
For Standard Frames, writes to this bit should be 0
Name TXFIFO_DLC
Relative Address 0x00000034
Absolute Address can0: 0xE0008034
can1: 0xE0009034
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description transmit message fifo data length code
Field Name Bits Type Reset Value Description
Field Name Bits Type Reset Value Description
DLC
(DLCR_DLC)
31:28 rw 0x0 Data Length Code
This is the data length portion of the control field
of the CAN frame. This indicates the number
valid data bytes in Data Word 1 and Data Word 2
registers.
reserved 27:0 rw 0x0 reserved
