Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 816
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (can) TXFIFO_DATA1
Register TXFIFO_DATA1 Details
Register (can) TXFIFO_DATA2
Name TXFIFO_DATA1
Software Name TXFIFO_DW1
Relative Address 0x00000038
Absolute Address can0: 0xE0008038
can1: 0xE0009038
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description transmit message fifo data word 1
Field Name Bits Type Reset Value Description
DB0
(DW1R_DB0)
31:24 rw 0x0 Data Byte 0
Reads from this field return invalid data if the
message has no data.
DB1
(DW1R_DB1)
23:16 rw 0x0 Data Byte 1
Reads from this field return invalid data if the
message has only 1 byte of data or fewer
DB2
(DW1R_DB2)
15:8 rw 0x0 Data Byte 2
Reads from this field return invalid data if the
message has only 2 byte of data or fewer
DB3
(DW1R_DB3)
7:0 rw 0x0 Data Byte 3
Reads from this field return invalid data if the
message has only 3 byte of data or fewer
Name TXFIFO_DATA2
Software Name TXFIFO_DW2
Relative Address 0x0000003C
Absolute Address can0: 0xE000803C
can1: 0xE000903C
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description transmit message fifo data word 2
