Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 823
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (can) RXFIFO_DATA2
Register RXFIFO_DATA2 Details
Register (can) AFR
DB2
(DW1R_DB2)
15:8 rw x Data Byte 2
Reads from this field return invalid data if the
message has only 2 byte of data or fewer
DB3
(DW1R_DB3)
7:0 rw x Data Byte 3
Reads from this field return invalid data if the
message has only 3 byte of data or fewer
Name RXFIFO_DATA2
Software Name RXFIFO_DW2
Relative Address 0x0000005C
Absolute Address can0: 0xE000805C
can1: 0xE000905C
Width 32 bits
Access Type rw
Reset Value x
Description receive message fifo data word 2
Field Name Bits Type Reset Value Description
Field Name Bits Type Reset Value Description
DB0
(DW2R_DB4)
31:24 rw x Data Byte 4
Reads from this field return invalid data if the
message has only 4 byte of data or fewer
DB1
(DW2R_DB5)
23:16 rw x Data Byte 5
Reads from this field return invalid data if the
message has only 5 byte of data or fewer
DB2
(DW2R_DB6)
15:8 rw x Data Byte 6
Reads from this field return invalid data if the
message has only 6 byte of data or fewer
DB3
(DW2R_DB7)
7:0 rw x Data Byte 7
Reads from this field return invalid data if the
message has 7 byte of data or fewer
Name AFR
Relative Address 0x00000060
