Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 824
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register AFR Details
The Acceptance Filter Register (AFR) defines which acceptance filters to use. Each Acceptance Filter ID
Register (AFIR) and Acceptance Filter Mask Register (AFMR) pair is associated with a UAF bit.
When the UAF bit is '1,' the corresponding acceptance filter pair is used for acceptance filtering. When the
UAF bit is '0,' the corresponding acceptance filter pair is not used for acceptance filtering.
To modify an acceptance filter pair in Normal mode, the corresponding UAF bit in this register must be set
to '0.'After the acceptance filter is modified, the corresponding UAF bit must be set to '1.'The following
conditions govern the number of UAF bits that can exist in the.
* If all UAF bits are set to '0,' then all received messages are stored in the RX FIFO
* If the UAF bits are changed from a '1' to '0' during reception of a CAN message, the message may not be
stored in the RX FIFO.
Absolute Address can0: 0xE0008060
can1: 0xE0009060
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description Acceptance Filter Register
Field Name Bits Type Reset Value Description
reserved 31:4 rw 0x0 reserved
UAF4 3 rw 0x0 Use Acceptance Filter Number 4
Enables the use of acceptance filter pair 4.
1: Indicates Acceptance Filter Mask Register 4 and
Acceptance Filter ID Register 4 are used for
acceptance filtering.
0: Indicates Acceptance Filter Mask Register 4 and
Acceptance Filter ID Register 4 are not used for
acceptance filtering.
UAF3 2 rw 0x0 Use Acceptance Filter Number 3
Enables the use of acceptance filter pair 3.
1: Indicates Acceptance Filter Mask Register 3 and
Acceptance Filter ID Register 3 are used for
acceptance filtering.
0: Indicates Acceptance Filter Mask Register 3 and
Acceptance Filter ID Register 3 are not used for
acceptance filtering.
