Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 828
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (can) AFMR2
Register AFMR2 Details
AIIDL 18:1 rw x Extended Message ID Mask Extended Identifier
AIRTR 0 rw x Remote Transmission Request Mask RTR bit for
Extended frames.
Name AFMR2
Relative Address 0x0000006C
Absolute Address can0: 0xE000806C
can1: 0xE000906C
Width 32 bits
Access Type rw
Reset Value x
Description Acceptance Filter Mask Register 2
Field Name Bits Type Reset Value Description
Field Name Bits Type Reset Value Description
AMIDH 31:21 rw x Standard Message ID Mask
These bits are used for masking the Identifier in a
Standard Frame.
1: Indicates the corresponding bit in Acceptance
Mask ID Register is used when comparing the
incoming message identifier.
0: Indicates the corresponding bit in Acceptance
Mask ID Register is not used when comparing the
incoming message identifier.
AMSRR 20 rw x Substitute Remote Transmission Request Mask
This bit is used for masking the RTR bit in a
Standard Frame.
1: Indicates the corresponding bit in Acceptance
Mask ID Register is used when comparing the
incoming message identifier.
0: Indicates the corresponding bit in Acceptance
Mask ID Register is not used when comparing the
incoming message identifier.
