Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 830
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register AFIR2 Details
Register (can) AFMR3
Description Acceptance Filter ID Register 2
Field Name Bits Type Reset Value Description
AIIDH 31:21 rw x Standard Message ID
Standard Identifier
AISRR 20 rw x Substitute Remote Transmission Request
Indicates the Remote Transmission Request bit for
Standard frames
AIIDE 19 rw x Identifier Extension
Differentiates between Standard and Extended
frames
AIIDL 18:1 rw x Extended Message ID Mask Extended Identifier
AIRTR 0 rw x Remote Transmission Request Mask RTR bit for
Extended frames.
Name AFMR3
Relative Address 0x00000074
Absolute Address can0: 0xE0008074
can1: 0xE0009074
Width 32 bits
Access Type rw
Reset Value x
Description Acceptance Filter Mask Register 3
