Appendix B: Register Details
CHE_UNCORR_ECC_
DATA_63_32_REG_OF
FSET
0x000000E8 32 ro 0x00000000 ECC unrecoverable error data
middle
CHE_UNCORR_ECC_
DATA_71_64_REG_OF
FSET
0x000000EC 8 ro 0x00000000 ECC unrecoverable error data
high
CHE_ECC_STATS_RE
G_OFFSET
0x000000F0 16 clron
wr
0x00000000 ECC error count
ECC_scrub
0x000000F4 4 rw 0x00000008 ECC mode/scrub
CHE_ECC_CORR_BIT
_MASK_31_0_REG_OF
FSET
0x000000F8 32 ro 0x00000000 ECC data mask low
CHE_ECC_CORR_BIT
_MASK_63_32_REG_O
FFSET
0x000000FC 32 ro 0x00000000 ECC data mask high
phy_rcvr_enable
0x00000114 8 rw 0x00000000 Phy receiver enable register
PHY_Config0
0x00000118 31 rw 0x40000001 PHY configuration register for
data slice 0.
PHY_Config1
0x0000011C 31 rw 0x40000001 PHY configuration register for
data slice 1.
PHY_Config2
0x00000120 31 rw 0x40000001 PHY configuration register for
data slice 2.
PHY_Config3
0x00000124 31 rw 0x40000001 PHY configuration register for
data slice 3.
phy_init_ratio0
0x0000012C 20 rw 0x00000000 PHY init ratio register for data
slice 0.
phy_init_ratio1
0x00000130 20 rw 0x00000000 PHY init ratio register for data
slice 1.
phy_init_ratio2
0x00000134 20 rw 0x00000000 PHY init ratio register for data
slice 2.
phy_init_ratio3
0x00000138 20 rw 0x00000000 PHY init ratio register for data
slice 3.
phy_rd_dqs_cfg0
0x00000140 20 rw 0x00000040 PHY read DQS configuration
register for data slice 0.
phy_rd_dqs_cfg1
0x00000144 20 rw 0x00000040 PHY read DQS configuration
register for data slice 1.
phy_rd_dqs_cfg2
0x00000148 20 rw 0x00000040 PHY read DQS configuration
register for data slice 2.
phy_rd_dqs_cfg3
0x0000014C 20 rw 0x00000040 PHY read DQS configuration
register for data slice 3.
phy_wr_dqs_cfg0
0x00000154 20 rw 0x00000000 PHY write DQS configuration
register for data slice 0.
Register Name Address Width Type Reset Value Description
