Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 839
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
phy_wr_dqs_cfg1 0x00000158 20 rw 0x00000000 PHY write DQS configuration
register for data slice 1.
phy_wr_dqs_cfg2
0x0000015C 20 rw 0x00000000 PHY write DQS configuration
register for data slice 2.
phy_wr_dqs_cfg3
0x00000160 20 rw 0x00000000 PHY write DQS configuration
register for data slice 3.
phy_we_cfg0
0x00000168 21 rw 0x00000040 PHY FIFO write enable
configuration for data slice 0.
phy_we_cfg1
0x0000016C 21 rw 0x00000040 PHY FIFO write enable
configuration for data slice 1.
phy_we_cfg2
0x00000170 21 rw 0x00000040 PHY FIFO write enable
configuration for data slice 2.
phy_we_cfg3
0x00000174 21 rw 0x00000040 PHY FIFO write enable
configuration for data slice 3.
wr_data_slv0
0x0000017C 20 rw 0x00000080 PHY write data slave ratio
config for data slice 0.
wr_data_slv1
0x00000180 20 rw 0x00000080 PHY write data slave ratio
config for data slice 1.
wr_data_slv2
0x00000184 20 rw 0x00000080 PHY write data slave ratio
config for data slice 2.
wr_data_slv3
0x00000188 20 rw 0x00000080 PHY write data slave ratio
config for data slice 3.
reg_64
0x00000190 32 rw 0x10020000 Training control 2
reg_65
0x00000194 20 rw 0x00000000 Training control 3
reg69_6a0
0x000001A4 29 ro 0x00070000 Training results for data slice 0.
reg69_6a1
0x000001A8 29 ro 0x00060200 Training results for data slice 1.
reg6c_6d2
0x000001B0 28 ro 0x00040600 Training results for data slice 2.
reg6c_6d3
0x000001B4 28 ro 0x00000E00 Training results for data slice 3.
reg6e_710
0x000001B8 30 ro x Training results (2) for data slice
0.
reg6e_711
0x000001BC 30 ro x Training results (2) for data slice
1.
reg6e_712
0x000001C0 30 ro x Training results (2) for data slice
2.
reg6e_713
0x000001C4 30 ro x Training results (2) for data slice
3.
phy_dll_sts0
0x000001CC 27 ro 0x00000000 Slave DLL results for data slice
0.
phy_dll_sts1
0x000001D0 27 ro 0x00000000 Slave DLL results for data slice
1.
Register Name Address Width Type Reset Value Description
