Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 840
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
phy_dll_sts2 0x000001D4 27 ro 0x00000000 Slave DLL results for data slice
2.
phy_dll_sts3
0x000001D8 27 ro 0x00000000 Slave DLL results for data slice
3.
dll_lock_sts
0x000001E0 24 ro 0x00F00000 DLL Lock Status, read
phy_ctrl_sts
0x000001E4 30 ro x PHY Control status, read
phy_ctrl_sts_reg2
0x000001E8 27 ro 0x00000013 PHY Control status (2), read
axi_id
0x00000200 26 ro 0x00153042 ID and revision information
page_mask
0x00000204 32 rw 0x00000000 Page mask
axi_priority_wr_port0
0x00000208 20 mixed 0x000803FF AXI Priority control for write
port 0.
axi_priority_wr_port1
0x0000020C 20 mixed 0x000803FF AXI Priority control for write
port 1.
axi_priority_wr_port2
0x00000210 20 mixed 0x000803FF AXI Priority control for write
port 2.
axi_priority_wr_port3
0x00000214 20 mixed 0x000803FF AXI Priority control for write
port 3.
axi_priority_rd_port0
0x00000218 20 mixed 0x000003FF AXI Priority control for read
port 0.
axi_priority_rd_port1
0x0000021C 20 mixed 0x000003FF AXI Priority control for read
port 1.
axi_priority_rd_port2
0x00000220 20 mixed 0x000003FF AXI Priority control for read
port 2.
axi_priority_rd_port3
0x00000224 20 mixed 0x000003FF AXI Priority control for read
port 3.
excl_access_cfg0
0x00000294 18 rw 0x00000000 Exclusive access configuration
for port 0.
excl_access_cfg1
0x00000298 18 rw 0x00000000 Exclusive access configuration
for port 1.
excl_access_cfg2
0x0000029C 18 rw 0x00000000 Exclusive access configuration
for port 2.
excl_access_cfg3
0x000002A0 18 rw 0x00000000 Exclusive access configuration
for port 3.
mode_reg_read
0x000002A4 32 ro 0x00000000 Mode register read data
lpddr_ctrl0
0x000002A8 12 rw 0x00000000 LPDDR2 Control 0
lpddr_ctrl1
0x000002AC 32 rw 0x00000000 LPDDR2 Control 1
lpddr_ctrl2
0x000002B0 22 rw 0x003C0015 LPDDR2 Control 2
lpddr_ctrl3
0x000002B4 18 rw 0x00000601 LPDDR2 Control 3
Register Name Address Width Type Reset Value Description
