Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 856
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (ddrc) DRAM_addr_map_col
Register DRAM_addr_map_col Details
Selects the address bits used as DRAM column address bits
Field Name Bits Type Reset Value Description
reg_ddrc_addrmap_col
_b6
19:16 rw 0x0 Full bus width mode: Selects the address bits used
as column address bits 7.
Half bus width mode:
Selects the address bits used as column address
bits 8. Valid range is 0-7. Internal Base 9. The
selected address bit for each of the column
address bits is determined by adding the Internal
Base to the value of this field.
reg_ddrc_addrmap_col
_b5
15:12 rw 0x0 Full bus width mode: Selects the address bits used
as column address bits 6.
Half bus width mode:
Selects the address bits used as column address
bits 7. Valid range is 0-7. Internal Base 8. The
selected address bit for each of the column
address bits is determined by adding the Internal
Base to the value of this field.
reg_ddrc_addrmap_ba
nk_b2
11:8 rw 0xF Selects the AXI address bit used as bank address
bit 2. Valid range 0 to 14, and 15. Internal Base: 7.
The selected address bit is determined by adding
the Internal Base to the value of this field. If set to
15, bank address bit 2 is set to 0.
reg_ddrc_addrmap_ba
nk_b1
7:4 rw 0x7 Selects the address bits used as bank address bit 1.
Valid Range: 0 to 14; Internal Base: 6.
The selected address bit for each of the bank
address bits is determined by adding the Internal
Base to the value of this field.
reg_ddrc_addrmap_ba
nk_b0
3:0 rw 0x7 Selects the address bits used as bank address bit 0.
Valid Range: 0 to 14. Internal Base: 5.
The selected address bit for each of the bank
address bits is determined by adding the Internal
Base to the value of this field.
Name DRAM_addr_map_col
Relative Address 0x00000040
Absolute Address 0xF8006040
Width 32 bits
Access Type rw
Reset Value 0xFFF00000
Description Column address bits
