Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 863
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (ddrc) phy_cmd_timeout_rddata_cpt
phy_reg_bc_fifo_we2 14 ro 0x0 Debug read capture FIFO write enable, for data
slice 2.
phy_reg_bc_dqs_oe2 13 ro 0x0 Debug DQS output enable for data slice 2.
phy_reg_bc_dq_oe2 12 ro 0x0 Debug DQ output enable for data slice 2.
phy_reg_bc_fifo_re1 11 ro 0x0 Debug read capture FIFO read enable for data
slice 1.
phy_reg_bc_fifo_we1 10 ro 0x0 Debug read capture FIFO write enable, for data
slice 1.
phy_reg_bc_dqs_oe1 9 ro 0x0 Debug DQS output enable for data slice 1.
phy_reg_bc_dq_oe1 8 ro 0x0 Debug DQ output enable for data slice 1.
phy_reg_bc_fifo_re0 7 ro 0x0 Debug read capture FIFO read enable for data
slice 0.
phy_reg_bc_fifo_we0 6 ro 0x0 Debug read capture FIFO write enable, for data
slice 0.
phy_reg_bc_dqs_oe0 5 ro 0x0 Debug DQS output enable for data slice 0.
phy_reg_bc_dq_oe0 4 ro 0x0 Debug DQ output enable for data slice 0.
phy_reg_rdc_fifo_rst_e
rr_cnt
3:0 ro 0x0 Counter for counting how many times the
pointers of read capture FIFO differ when they are
reset by dll_calib.
Name phy_cmd_timeout_rddata_cpt
Relative Address 0x00000050
Absolute Address 0xF8006050
Width 32 bits
Access Type mixed
Reset Value 0x00010200
Description PHY command time out and read data capture FIFO
Field Name Bits Type Reset Value Description
